46M0853 Контроллер IBM ServeRAID 5025 SAS/SATAi
46M0853 Контроллер IBM ServeRAID 5025 SAS/SATAi
Артикул:
46M0853
Вес:
0
кг.
Есть в наличии
Количество:
Цвет:
41 850
руб.
Description:IBM ServeRAID M5025 PCI-e SAS/SATA RAID ControllerPart Number(s)
IBM Part# 46M0853
IBM Option Part# 46M0830
Overview:
The ServeRAID M5025 SAS/SATA Controller for IBM System x is the next-generation 6 Gbps SAS 2.0 external RAID controller. This adapter has two external mini-SAS connectors to control up to 240 devices and supports global and dedicated hot-spare drives. The ServeRAID M5025 controller delivers a full 6-Gbps SAS 2.0 RAID solution with the performance advantages of an extended cache and a standard battery backup unit. With the attachment of the ServeRAID M5000 Advanced Feature Key - the ServeRAID M5025 offers the option of RAID 6 - RAID 60 and SED Encryption Key Management.
Specifications:
CategoryIBM Option
Sub-CategoryController
GenerationSAS/SATA PCIe
Part Number46M0853
Products ID461622
Controller TypeStorage Controller (RAID)
InterfaceSerial Attached SCSI (SAS)
Recommended Machine TypeServer
PlatformServer
Bus TypePCIe 2.0 X8
Data Transfer Rate6GB/s
Supported RAID LevelRaid 0 1 10 5 50
Form FactorPlug-in Card
Connector Location External
Enlarge Image of Part# 46M0853
-
ПоставщикSERVERGEAR
-
СовместимостьSystem x3250 M3 x3620 M3 x3650 M3 x3950 X5
-
Тип товараКонтроллер
