N2K-C2248TP-1GE CISCO Cisco Nexus N2K-C2248TP-1GE (48x100/1000-T+4x10GE)
N2K-C2248TP-1GE CISCO Cisco Nexus N2K-C2248TP-1GE (48x100/1000-T+4x10GE)
Артикул:
N2K-C2248TP-1GE
Вес:
0
кг.
Есть в наличии
Количество:
Цвет:
23 650
руб.
Compatibility: N2K-C2248TP-1GE
-
10G supportYes
-
Access Control List (ACL)Yes
-
Basic switching RJ-45 Ethernet ports quantity48
-
CertificationCE, 47CFR, AS/NZS CISPR, EN, VCCI, KN22, CNS, RoHS
-
Co2 Savings343.78 KG
-
Colour of productSilver
-
Compatible productsNexus 5000 Nexus 7000
-
Connectivity technologyWired
-
Copper ethernet cabling technology1000BASE-T, 1000BASE-TX, 100BASE-TX
-
Dimensions (W x D x H) (imperial)449.6 x 439.4 x 43.7 mm (17.7 x 17.3 x 1.72")
-
Dimensions (WxDxH)449.6 x 439.4 x 43.7 mm
-
Fiber ethernet cabling technology10GBASE-LR, 10GBASE-SR
-
Fiber ports quantity4
-
Flow control supportYes
-
Full duplexYes
-
Heat dissipation403 BTU/h
-
Input current1.2 A
-
Input frequency50/60 Hz
-
Input voltage90 - 264 V
-
Jumbo frames supportYes
-
MAC address table8000 entries
-
Management protocolsSNMP v1/v2c/v3
-
Maximum data transfer rate40 Gbit/s
-
MIB supportENTITY-MIB, IF-MIB, EXT-MIB, ENTITY-EXT-MIB, ENTITY-FRU-CNTRL-MIB, ENTITY-SNSR-MIB, ETH-EXT-MIB
-
Multicast supportYes
-
Networking featuresGigabit Ethernet
-
Networking standardsIEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x
-
Number of fans1 fan(s)
-
Number of power supply units2
-
Number of queues8
-
Operating altitude0 - 3000 m
-
Operating temperature (T-T)0 - 40 °C
-
Packet transfer speed9216 b
-
Power consumption (typical)110 W
-
Power over Ethernet (PoE)No
-
Power requirements100 - 220V
-
Power supply400 W
-
Quality of Service (QoS) supportYes
-
Redundant power supply (RPS) supportYes
-
Relative humidity5 - 95%
-
Remote administrationRMON
-
SafetyUL 60950-1, CAN/CSA-C22.2, IEC 60950-1AS/NZS
-
Spanning tree protocolYes
-
Static port securityYes
-
Storage temperature (T-T)-20 - 70 °C
-
Store-and-forwardYes
-
Supported data transfer rates10/100/1000 Mbps
-
Switch layerL2
-
Switch typeManaged
-
Switching capacity176 Gbit/s
-
System event logYes
-
Warranty1 Year
-
Weight8 kg
-
Weight (imperial)8.16 kg (18 lbs)
-
ПоставщикSERVERGEAR
-
ПроизводительCisco
-
Тип товараПереключатель
